★★200KW CUMMINS diesel gensets specification★★
|
|
★Diesel gensets parameter:
|
|
Model number:KWHQ200GF
|
Steady state voltage regulation(%):≤±1
|
Output power:200KW
|
Voltage fluctuation rate(%):≤±0.5
|
Pwer factor:COSΦ=0.8(lagger)
|
Transient voltage regulation(%):+20~-15
|
Output voltage:400V/230V
|
Voltage settling time(s):≤1
|
Output currency:360A
|
Steady state frequency regulation(%):≤±1
|
Rated frequency:50Hz
|
Frequency fluctuation rate(%):≤±0.5
|
Rated RPM:1500rpm
|
Transient frequency adjustment rate(%):+10~-7
|
Fuel brand:(Standard) 0# light diesel oil (at room temperature)
|
Frequency stabilization time(S):≤3
|
Overall size:2600*1180*1600(L×W×H mm)
|
Oil consumption(100% loading):≤205g/kW·h
|
NET WEIGHT:1800kg
|
Noise(LP7m):95dB(A)
|
★Diesel engine parameter:
|
|
Brand:DCEC CUMMINS
|
Cooling mode:full-closed water-cooling
|
Model number:6LTAA8.9-G2
|
Supply oil type:direct injection
|
Rated power:220kw
|
Standby power:240kw
|
Displacement:8.9 Liters
|
Fuel system: Beiyou P7100 pump/GAC electronic governor
|
Cylinder number:6/L type
|
Governor type:Electronic Speed Regulation
|
Bore & Stroke:114*145 mm
|
Intake:Turbo Charge
|
Compression:16.6:1
|
Loading capacity:110%
|
Starting mode:DC24V electric
|
RPM:1500rpm
|
Lubricant capacity:
|
27.6 Liters
|
Coolant Capacity:
|
11.1 Liters
|
★Alternator parameter:
|
|
Brand:Kangwo
|
Indication of protection:IP23
|
Model number:HQF-XN180
|
Connecting type: Three phase and 4 wires,“Y”type
|
Rated power:180KW
|
Regulating type:AVR(Automatic voltage regulator)
|
Rated voltage:400V/230V
|
Output frequency:50Hz
|
Insulation class:H grade
|
Power factor:COSΦ=0.8(lagger)
|
★★250KW CUMMINS diesel gensets specification★★
|
|
★Diesel gensets parameter:
|
|
Model number:KWHQ250GF
|
Steady state voltage regulation(%):≤±1
|
Output power:250KW
|
Voltage fluctuation rate(%):≤±0.5
|
Pwer factor:COSΦ=0.8(lagger)
|
Transient voltage regulation(%):+20~-15
|
Output voltage:400V/230V
|
Voltage settling time(s):≤1
|
Output currency:450A
|
Steady state frequency regulation(%):≤±1
|
Rated frequency:50Hz
|
Frequency fluctuation rate(%):≤±0.5
|
Rated RPM:1500rpm
|
Transient frequency adjustment rate(%):+10~-7
|
Fuel brand:(Standard) 0# light diesel oil (at room temperature)
|
Frequency stabilization time(S):≤3
|
Overall size:3150*1180*1700(L×W×H mm)
|
Oil consumption(100% loading):≤205g/kW·h
|
NET WEIGHT:3100kg
|
Noise(LP7m):95dB(A)
|
★Diesel engine parameter:
|
|
Brand:DCEC CUMMINS
|
Cooling mode:full-closed water-cooling
|
Model number:QSM11-G2
|
Supply oil type:direct injection
|
Rated power:292kw
|
Standby power:319kw
|
Displacement:8.9 Liters
|
Fuel system: Beiyou P7100 pump/GAC electronic governor
|
Cylinder number:6/L type
|
Governor type:Electric Injection
|
Bore & Stroke:114*145 mm
|
Intake:Turbo Charge
|
Compression:17.73:1
|
Loading capacity:110%
|
Starting mode:DC24V electric
|
RPM:1500rpm
|
Lubricant capacity:
|
27.6 Liters
|
Coolant Capacity:
|
11.1 Liters
|
★Alternator parameter:
|
|
Brand:Kangwo
|
Indication of protection:IP23
|
Model number:HQF-XN250
|
Connecting type: Three phase and 4 wires,“Y”type
|
Rated power:250KW
|
Regulating type:AVR(Automatic voltage regulator)
|
Rated voltage:400V/230V
|
Output frequency:50Hz
|
Insulation class:H grade
|
Power factor:COSΦ=0.8(lagger)
|
★★300KW CUMMINS diesel gensets specification★★
|
|
★Diesel gensets parameter:
|
|
Model number:KWHQ300GF
|
Steady state voltage regulation(%):≤±1
|
Output power:300KW
|
Voltage fluctuation rate(%):≤±0.5
|
Pwer factor:COSΦ=0.8(lagger)
|
Transient voltage regulation(%):+20~-15
|
Output voltage:400V/230V
|
Voltage settling time(s):≤1
|
Output currency:540A
|
Steady state frequency regulation(%):≤±1
|
Rated frequency:50Hz
|
Frequency fluctuation rate(%):≤±0.5
|
Rated RPM:1500rpm
|
Transient frequency adjustment rate(%):+10~-7
|
Fuel brand:(Standard) 0# light diesel oil (at room temperature)
|
Frequency stabilization time(S):≤3
|
Overall size:3250*1180*1800(L×W×H mm)
|
Oil consumption(100% loading):≤209g/kW·h
|
NET WEIGHT:3200kg
|
Noise(LP7m):95dB(A)
|
★Diesel engine parameter:
|
|
Brand:DCEC CUMMINS
|
Cooling mode:full-closed water-cooling
|
Model number:NTA855-G7A
|
Supply oil type:direct injection
|
Cylinder number:6/L type
|
Governor type:Electric Speed Regulation
|
Bore & Stroke:140*152 mm
|
Intake:Turbo Charge
|
Compression:14:1
|
Loading capacity:110%
|
Starting mode:DC24V electric
|
RPM:1500rpm
|
★Alternator parameter:
|
|
Brand:Kangwo
|
Indication of protection:IP22
|
Model number:XN4F
|
Connecting type: Three phase and 4 wires,“Y”type
|
Rated power:300KW
|
Regulating type:AVR(Automatic voltage regulator)
|
Rated voltage:400V/230V
|
Output frequency:50Hz
|
Insulation class:H grade
|
Power factor:COSΦ=0.8(lagger)
|
★★350KW CUMMINS diesel gensets specification★★
|
|
★Diesel gensets parameter:
|
|
Model number:KWHQ350GF
|
Steady state voltage regulation(%):≤±1
|
Output power:350KW
|
Voltage fluctuation rate(%):≤±0.5
|
Pwer factor:COSΦ=0.8(lagger)
|
Transient voltage regulation(%):+20~-15
|
Output voltage:400V/230V
|
Voltage settling time(s):≤1
|
Output currency:630A
|
Steady state frequency regulation(%):≤±1
|
Rated frequency:50Hz
|
Frequency fluctuation rate(%):≤±0.5
|
Rated RPM:1500rpm
|
Transient frequency adjustment rate(%):+10~-7
|
Fuel brand:(Standard) 0# light diesel oil (at room temperature)
|
Frequency stabilization time(S):≤3
|
Overall size:3350*1450*1750(L×W×H mm)
|
Oil consumption(100% loading):≤205g/kW·h
|
NET WEIGHT:3250kg
|
Noise(LP7m):95dB(A)
|
★Diesel engine parameter:
|
|
Brand:DCEC CUMMINS
|
Cooling mode:full-closed water-cooling
|
Model number:NTAA855-G7A
|
Supply oil type:direct injection
|
Cylinder number:6/L type
|
Governor type:Electric Speed Regulation
|
Bore & Stroke:140*152 mm
|
Intake:Turbo Charge
|
Compression:14:1
|
Loading capacity:110%
|
Starting mode:DC24V electric
|
RPM:1500rpm
|
★Alternator parameter:
|
|
Brand:Kangwo
|
Indication of protection:IP22
|
Model number:XN5C
|
Connecting type: Three phase and 4 wires,“Y”type
|
Rated power:350KW
|
Regulating type:AVR(Automatic voltage regulator)
|
Rated voltage:400V/230V
|
Output frequency:50Hz
|
Insulation class:H grade
|
Power factor:COSΦ=0.8(lagger)
|
★★400KW CUMMINS diesel gensets specification★★
|
|
★Diesel gensets parameter:
|
|
Model number:KWHQ400GF
|
Steady state voltage regulation(%):≤±1
|
Output power:400KW
|
Voltage fluctuation rate(%):≤±0.5
|
Pwer factor:COSΦ=0.8(lagger)
|
Transient voltage regulation(%):+20~-15
|
Output voltage:400V/230V
|
Voltage settling time(s):≤1
|
Output currency:720A
|
Steady state frequency regulation(%):≤±1
|
Rated frequency:50Hz
|
Frequency fluctuation rate(%):≤±0.5
|
Rated RPM:1500rpm
|
Transient frequency adjustment rate(%):+10~-7
|
Fuel brand:(Standard) 0# light diesel oil (at room temperature)
|
Frequency stabilization time(S):≤3
|
Overall size:3650*1680*1800(L×W×H mm)
|
Oil consumption(100% loading):≤205g/kW·h
|
NET WEIGHT:3800kg
|
Noise(LP7m):95dB(A)
|
★Diesel engine parameter:
|
|
Brand:DCEC CUMMINS
|
Cooling mode:full-closed water-cooling
|
Model number:QSZ13-G5
|
Supply oil type:direct injection
|
Rated power:411kw
|
Standby power:470kw
|
Displacement:13.0 Liters
|
Fuel system: Beiyou P7100 pump/GAC electronic governor
|
Cylinder number:6/L type
|
Governor type:Electric Speed Regulation
|
Bore & Stroke:130*163 mm
|
Intake:Turbo Charge
|
Compression:17:1
|
Loading capacity:110%
|
Starting mode:DC24V electric
|
RPM:1500rpm
|
Lubricant capacity:
|
45.42 Liters
|
Coolant Capacity:
|
23.1 Liters
|
★Alternator parameter:
|
|
Brand:Kangwo
|
Indication of protection:IP23
|
Model number:HQF-XN400
|
Connecting type: Three phase and 4 wires,“Y”type
|
Rated power:400KW
|
Regulating type:AVR(Automatic voltage regulator)
|
Rated voltage:400V/230V
|
Output frequency:50Hz
|
Insulation class:H grade
|
Power factor:COSΦ=0.8(lagger)
|
★★500KW CUMMINS diesel gensets specification★★
|
|
★Diesel gensets parameter:
|
|
Model number:KWHQ500GF
|
Steady state voltage regulation(%):≤±1
|
Output power:500KW
|
Voltage fluctuation rate(%):≤±0.5
|
Pwer factor:COSΦ=0.8(lagger)
|
Transient voltage regulation(%):+20~-15
|
Output voltage:400V/230V
|
Voltage settling time(s):≤1
|
Output currency:900A
|
Steady state frequency regulation(%):≤±1
|
Rated frequency:50Hz
|
Frequency fluctuation rate(%):≤±0.5
|
Rated RPM:1500rpm
|
Transient frequency adjustment rate(%):+10~-7
|
Fuel brand:(Standard) 0# light diesel oil (at room temperature)
|
Frequency stabilization time(S):≤3
|
Overall size:3600*1600*1850(L×W×H mm)
|
Oil consumption(100% loading):≤209g/kW·h
|
NET WEIGHT:3650kg
|
Noise(LP7m):95dB(A)
|
★Diesel engine parameter:
|
|
Brand:DCEC CUMMINS
|
Cooling mode:full-closed water-cooling
|
Model number:KTAA19-G6A
|
Supply oil type:direct injection
|
Rated power:555kw
|
Standby power:610kw
|
Cylinder number:6/L type
|
Governor type:Electric Speed Regulation
|
Bore & Stroke:159*159 mm
|
Intake:Turbo Charge
|
Compression:13:1
|
Loading capacity:110%
|
Starting mode:DC24V electric
|
RPM:1500rpm
|
Oil capacity: 34.9 Liters
|
Coolant Capacity:20.8 Liters
|
★Alternator parameter:
|
|
Brand:Kangwo
|
Indication of protection:IP23
|
Model number:HQF-XN500
|
Connecting type: Three phase and 4 wires,“Y”type
|
Rated power:500KW
|
Regulating type:AVR(Automatic voltage regulator)
|
Rated voltage:400V/230V
|
Output frequency:50Hz
|
Insulation class:H grade
|
Power factor:COSΦ=0.8(lagger)
|
★★600KW CUMMINS diesel gensets specification★★
|
|
★Diesel gensets parameter:
|
|
Model number:KWHQ600GF
|
Steady state voltage regulation(%):≤±1
|
Output power:600KW
|
Voltage fluctuation rate(%):≤±0.5
|
Pwer factor:COSΦ=0.8(lagger)
|
Transient voltage regulation(%):+20~-15
|
Output voltage:400V/230V
|
Voltage settling time(s):≤1
|
Output currency:1080A
|
Steady state frequency regulation(%):≤±1
|
Rated frequency:50Hz
|
Frequency fluctuation rate(%):≤±0.5
|
Rated RPM:1500rpm
|
Transient frequency adjustment rate(%):+10~-7
|
Fuel brand:(Standard) 0# light diesel oil (at room temperature)
|
Frequency stabilization time(S):≤3
|
Overall size:3700*1650*1900(L×W×H mm)
|
Oil consumption(100% loading):≤212g/kW·h
|
NET WEIGHT:4000kg
|
Noise(LP7m):105dB(A)
|
★Diesel engine parameter:
|
|
Brand:DCEC CUMMINS
|
Cooling mode:full-closed water-cooling
|
Model number:KTA38-GA
|
Supply oil type:direct injection
|
Rated power:647Kw
|
Standby power:711kw
|
Displacement:38 Liters
|
|
Cylinder number:6/L type
|
Governor type:Electric Speed Regulation
|
Bore & Stroke:159*159 mm
|
Intake:Turbo Charge
|
Compression:13:1
|
Loading capacity:110%
|
Starting mode:DC24V electric
|
RPM:1500rpm
|
★Alternator parameter:
|
|
Brand:Kangwo
|
Indication of protection:IP23
|
Model number:HQF-DK600
|
Connecting type: Three phase and 4 wires,“Y”type
|
Rated power:600KW
|
Regulating type:AVR(Automatic voltage regulator)
|
Rated voltage:400V/230V
|
Output frequency:50Hz
|
Insulation class:H grade
|
Power factor:COSΦ=0.8(lagger)
|
